Virtualize Legacy XP applications Using VirtualBox and Thinfinity

Virtualize Legacy XP applications Using VirtualBox and Thinfinity

Did you know that you are able to virtualize your legacy applications developed for Windows XP by utilizing one or more VirtualBox VM’s with Windows XP installed?
This solution will permit you to run them using any web browser, without making any changes to the VirtualBox is a free open source Hypervisor developed by Oracle, you can use it to create a virtualized environment and Run Windows XP Legacy applications on it.
You would be required to have Thinfinity Remote Desktop installed on a server and have a Windows XP installation file (.iso)
In order to accomplish this, you would need to follow these steps:
*Please note that you would need to disable Hyper-V for Windows 10 and Server 2016 on Windows Features for VirtualBox to work properly*

1. Go to the VirtualBox download site and click on “Windows hosts” to get the latest version of the Windows emulator:
Virtualize XP software applications

2. Once the setup is downloaded, proceed with the VirtualBox installation:
Virtualize XP software applications

3. Once VirtualBox is installed, open it and click on “New”:
Virtualize XP software applications

4. On the Create Virtual Machine window type a Name for the O.S. and click on “Create”:
Virtualize XP software applications

5. Leave the default options and click on “Create”:
Virtualize XP software applications

6. Now you should see the created O.S. Select it and click on “Start”:
Virtualize XP software applications

7. Now you’ll be prompted to select the Windows XP installation file, click on the folder icon:
Virtualize XP software applications

8. Then click on “Add” then look for the path of the image file of Windows XP and finally press “Start”:
Virtualize XP software applications

9. The Windows XP installation will now be shown. Press Enter on “Unpartitioned space”:
Virtualize XP software applications

10. Now select the “Format the partition using the NTFS file system (Quick) and press Enter:
Virtualize XP software applications

11. After the format is complete, the installation proper will commence. In here you’ll be prompted to type a Name and an Organization, then click “Next”:
Virtualize XP software applications

12. Now you would need to enter a “Computer name”, then “Next” twice:
Virtualize XP software applications

13. When prompted to select how to connect to Internet, choose the first option, like so:
Virtualize XP software applications

14. Type a Username:
Virtualize XP software applications

15. Now that Windows XP is installed, shut it down and click on “Settings”. Once there go to the “Network” tab, select “Internal Network”, “PCnet-FAST III” Adapter Type and “Allow VMs”. Then click OK:
Virtualize XP software applications

16. Power on the Windows XP VM again and go to My Computer > Properties > Remote tab and enable “Allow users to connect remotely to this computer”. Then click on “Select Remote Users” and add the Windows XP username you created:
Virtualize XP software applications

17. Now that the Windows XP VM is configured, go back to the server where Remote Desktop Server is installed and open its Server Manager. Go to the “Access Profiles” tab and click on “Add” > “RDP”
(For information on how to install Remote Desktop Server, please follow this tutorial).
Virtualize XP software applications

18. Enter the IP belonging to the Windows XP Virtual Machine and then you have the option to set up its username and password. Then click on “OK” and “Apply”:
Virtualize XP software applications
And that’s it! You are now able to access your legacy apps with Thinfinity Remote Desktop.
Virtualize XP software applications
Should you have any questions, contact us at [email protected] or leave a message on this same post.
